Getting Started with Angular Material

5 min readJan 22, 2024

by Vihan Gammanpila / January 23, 2024

This article will provide an overview of how to get started with Angular Material, a UI component library that implements Material Design in Angular. This article details the process of configuring an Angular application for incorporating Angular Material. It includes steps to showcase the utilization of material components, as illustrated in the following sections.

Set up

Generate the app

Generate a new Angular app and add Angular Material.

Use Angular CLI to generate a new Angular App

Run ng new my-app in the command line, replacing my-app with the name of the app.

2. Add Angular Material

Run the following commands

cd my-app
ng add @angular/material

Remove defaults

The current content is auto-generated by Angular in the first step, but we want to create our own.

Remove everything in app.component.html except for <router-outlet></router-outlet>.

Create the material module

First, to use material components in our app, they must be imported. Make a new file named material.module.ts. This is where you'll bring in each component. After that, this material module gets added to our app.

It’s possible, but not suggested, to add material components straight into the app.module.ts file.

For now, we’ll bring in every component Angular Material offers. This way, everything’s set up and ready. Later, you can change this to include only what you need.

Here’s what to do:

In src\app, make a new folder named material.
Inside this, make a file called material.module.ts. Put the following details in this file."

import { NgModule } from '@angular/core';
import { A11yModule } from '@angular/cdk/a11y';
import { ClipboardModule } from '@angular/cdk/clipboard';
import { DragDropModule } from '@angular/cdk/drag-drop';
import { PortalModule } from '@angular/cdk/portal';
import { ScrollingModule } from '@angular/cdk/scrolling';
import { CdkStepperModule } from '@angular/cdk/stepper';
import { CdkTableModule } from '@angular/cdk/table';
import { CdkTreeModule } from '@angular/cdk/tree';
import { MatAutocompleteModule } from '@angular/material/autocomplete';
import { MatBadgeModule } from '@angular/material/badge';
import { MatBottomSheetModule } from '@angular/material/bottom-sheet';
import { MatButtonModule } from '@angular/material/button';
import { MatButtonToggleModule } from '@angular/material/button-toggle';
import { MatCardModule } from '@angular/material/card';
import { MatCheckboxModule } from '@angular/material/checkbox';
import { MatChipsModule } from '@angular/material/chips';
import { MatStepperModule } from '@angular/material/stepper';
import { MatDatepickerModule } from '@angular/material/datepicker';
import { MatDialogModule } from '@angular/material/dialog';
import { MatDividerModule } from '@angular/material/divider';
import { MatExpansionModule } from '@angular/material/expansion';
import { MatGridListModule } from '@angular/material/grid-list';
import { MatIconModule } from '@angular/material/icon';
import { MatInputModule } from '@angular/material/input';
import { MatListModule } from '@angular/material/list';
import { MatMenuModule } from '@angular/material/menu';
import { MatNativeDateModule, MatRippleModule } from '@angular/material/core';
import { MatPaginatorModule } from '@angular/material/paginator';
import { MatProgressBarModule } from '@angular/material/progress-bar';
import { MatProgressSpinnerModule } from '@angular/material/progress-spinner';
import { MatRadioModule } from '@angular/material/radio';
import { MatSelectModule } from '@angular/material/select';
import { MatSidenavModule } from '@angular/material/sidenav';
import { MatSliderModule } from '@angular/material/slider';
import { MatSlideToggleModule } from '@angular/material/slide-toggle';
import { MatSnackBarModule } from '@angular/material/snack-bar';
import { MatSortModule } from '@angular/material/sort';
import { MatTableModule } from '@angular/material/table';
import { MatTabsModule } from '@angular/material/tabs';
import { MatToolbarModule } from '@angular/material/toolbar';
import { MatTooltipModule } from '@angular/material/tooltip';
import { MatTreeModule } from '@angular/material/tree';

@NgModule({
  exports: [
    A11yModule,
    ClipboardModule,
    CdkStepperModule,
    CdkTableModule,
    CdkTreeModule,
    DragDropModule,
    MatAutocompleteModule,
    MatBadgeModule,
    MatBottomSheetModule,
    MatButtonModule,
    MatButtonToggleModule,
    MatCardModule,
    MatCheckboxModule,
    MatChipsModule,
    MatStepperModule,
    MatDatepickerModule,
    MatDialogModule,
    MatDividerModule,
    MatExpansionModule,
    MatGridListModule,
    MatIconModule,
    MatInputModule,
    MatListModule,
    MatMenuModule,
    MatNativeDateModule,
    MatPaginatorModule,
    MatProgressBarModule,
    MatProgressSpinnerModule,
    MatRadioModule,
    MatRippleModule,
    MatSelectModule,
    MatSidenavModule,
    MatSliderModule,
    MatSlideToggleModule,
    MatSnackBarModule,
    MatSortModule,
    MatTableModule,
    MatTabsModule,
    MatToolbarModule,
    MatTooltipModule,
    MatTreeModule,
    PortalModule,
    ScrollingModule,
  ]
})
export class MaterialModule { }

This file takes in every material component available. Then, it puts them in a MaterialModule. This module makes them accessible to our app.

Import the material module

In app.module.ts, an import statement to the material module created in the last step.

Finally, put MaterialModule into the imports list of the AppModule. This step actually imports it into the app.

import { BrowserModule } from '@angular/platform-browser';
import { NgModule } from '@angular/core';

import { AppRoutingModule } from './app-routing.module';
import { AppComponent } from './app.component';
import { BrowserAnimationsModule } from '@angular/platform-browser/animations';
import { MaterialModule } from './material/material.module';

@NgModule({
declarations: [
  AppComponent
],
imports: [
  BrowserModule,
  AppRoutingModule,
  BrowserAnimationsModule,
  MaterialModule
],
providers: [],
bootstrap: [AppComponent]
})
export class AppModule { }

The app is all set to work with Angular Material. In the following step, we’ll add some content to the app. This will show how the material components look and function.

Add content

Create a component

Generate a component using Angular CLI

Run ng generate component home

2. Set up the routes

Replace the empty routes in app.routing.module.ts with

const routes: Routes = [
  { path: '', component: HomeComponent },
  { path: '**', redirectTo: '/', pathMatch: 'full' }
];

These steps have created a component called Home and set this as the base page.

To see it in action, just run ng serve. This compiles the app, and you should see the message 'home works!

Create a header toolbar bar

In app.component.html add a toolbar above the container div to be our app header

<mat-toolbar class="mat-elevation-z6" color="primary"></mat-toolbar>

Run ng-serve and open your browser to see the header at the top of the app.

We’ve successfully incorporated our initial Angular Material component. These components have a style that matches the theme. We chose the theme’s primary color for the bar by using the color attribute. Also, we used material elevation classes to give the components a shadowed, textured appearance.

Add Angular Material Components

Swap out the current contents in home.component.html with the code provided below. This code includes examples of material components. After that, refresh your browser. This will let you see the Angular Material components working.

<h1 class="mat-display-1">Easy, Breezy, Beautiful: Angular Material</h1>

<p>Here are some random angular material components</p>

<mat-card>
    <mat-card-header>
        <img mat-card-avatar src="https://cdn.pixabay.com/photo/2018/10/11/12/31/black-cat-3739702_1280.jpg"
            alt="My Photos">
        <mat-card-title>Easy, Breezy, Beautiful</mat-card-title>
        <mat-card-subtitle>Angular Material</mat-card-subtitle>
    </mat-card-header>
    <mat-card-content>
        <p>
            This is an amazing blog on Angular Material. Here is some awesome text about Angular Material.
            Here is some awesome text about Angular Material. Here is some awesome text about Angular Material.
            Here is some awesome text about Angular Material. Here is some awesome text about Angular Material.
            Here is some awesome text about Angular Material. Here is some awesome text about Angular Material.
        </p>
    </mat-card-content>
    <mat-card-actions align="end">
        <button mat-raised-button color="primary">Read More</button>
    </mat-card-actions>
</mat-card>

<div class="flex-container">
    <div>
        <button mat-raised-button color="primary">Raised Primary</button>
        <button mat-raised-button color="accent">Raised Accent</button>
        <button mat-stroked-button>Basic Stroked</button>
        <button mat-stroked-button color="primary">Stroked Primary</button>
    </div>

    <button mat-fab>
        <mat-icon>thumb_up</mat-icon>
    </button>

    <mat-radio-group aria-label="Select an option">
        <mat-radio-button value="1">Option 1</mat-radio-button>
        <mat-radio-button value="2">Option 2</mat-radio-button>
    </mat-radio-group>

    <mat-checkbox>Check me!</mat-checkbox>

    <mat-form-field>
        <mat-label>Choose a date</mat-label>
        <input matInput [matDatepicker]="picker">
        <mat-datepicker-toggle matSuffix [for]="picker"></mat-datepicker-toggle>
        <mat-datepicker #picker></mat-datepicker>
    </mat-form-field>

    <mat-slider></mat-slider>


    <button mat-flat-button color="primary" matTooltip="Info about the action" matTooltipPosition="after"
        aria-label="Button that displays a tooltip when focused or hovered over">
        Tooltip
    </button>
</div>

<mat-paginator [length]="100" [pageSize]="10" [pageSizeOptions]="[5, 10, 25, 100]"></mat-paginator>

Congratulations! Your Angular app now includes Angular Material.

For a complete list of components and their usage, take a look at the Angular Material documentation.
